CNC Notching&Marking Machine

The MF500C machines are versatile mult-unctional machine, which performs the notching, milig and marking operation in the same machine within same working procedure.MF500C machines have been proved to be high automatic, high precision, high efficiency and good safety.

High efficiency machining, notching 1 ring groove in about 15 minutes, engraving and milling marker in about 10 minutes,can also be less 4 Milling transverse rib groove angle in the standard range of arbitrary choice, can also be any empty slots.

Maximun turning diameter

Φ500mm

Maximun turning length

Φ2500mm—Φ3000mm

Apply To

Rebar 5mm—Rebar 60mm

1.The MF500C machines are versatile mult-unctional machine, which performs the notching, milig and marking operation in the same machine within same working procedure.MF500C machines have been proved to be high automatic, high precision, high efficiency and good safety.

2.The heavy-duty MF500C machines are built with three guides structure. The width reaches 910mm and the bed sadle reaches 810mm which highly improve the machines’rigidity and vibration resistance. These ensure MF500C can mill steel olls and tungsten carbide rollsin high speed.

3.High efficiency machining, notching 1 ring groove in about 15 minutes, engraving and milling marker in about 10 minutes,can also be less 4 Milling transverse rib groove angle in the standard range of arbitrary choice, can also be any empty slots.

4.The steel used in MF500C machine body are treated by ageing or annealing. The guideways are treated by intermediate frequencyquenching to increase the surface abrasion resistant.A rolling linear guide rail is employed for lateral feed to reduce friction and assure thehigh speed and precision.Under the normal condition, the linear guide has 10 years guarantee.

5.Machine tool assembly manual aligning cutter mechanism, and the saddle longitudinal movement with grating digital display, ensure themanual change slot displacement is accurate, eliminate the human visual caused by touching the edge cutting knife phenomenon.

6.Control uses SINUMERIK 808D system,LCD display. can realize any of three axes linkage.Fiul servo system of machine tool, 4 control axis are independent motor and drive.

Max.Roll Diameter 560mm
Max.Roll Length 2500mm
Max.Roll Surface Length 1800mm
Transverse Rib Groove Range ¢6—¢50
Marking Spindle Driving Power 2.2KW
Coolant Pump Motor Power AB25-90W
CNC Control System SIEMENS 808D
Grating Length Measurement 2000mm
Min.Programming Setting Unit 0.001
Min.Tool Feed 0.001mm
Machine Power 380V, 50HZ, 15KVA
Gross Weight 6500KG
